Name: 8 channels temperature collection Pt100 module support Modbus-RTU kingview configuration king
Brand: China Mall
Price: 361.58 SAR
Availability: InStock

Color

8 channels temperature collection Pt100 module support Modbus-RTU kingview configuration king

وحدة التحكم في درجة الحرارة ذات 8 قنوات ، وحدة التحكم Pt100 ، Modbus-RTU ، kingview

<div class="detailmodule_html"><div class="detail-desc-decorate-richtext"><div style="display:mangofig">
 <div style="height:0;overflow:hidden;">
  modname=ckeditor
 </div>
 <div>
  <div>
   <span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Basic functions: Support standard MODBUS-RTU devices such as Kingview, text, touch screen and PLC</span>
   <div>
    &nbsp;
   </div>
   <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Directly connected to Pt100, no transmitter required</span></p>
   <p>&nbsp;</p>
   <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">8 channels Pt100 temperature output, minimum resolution of measurement 0.1 degree (accuracy 0.5 degree), no transmitter, direct thermal resistance measurement.</span></p>
   <div>
    &nbsp;
   </div><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">1-way standard 485 communication port (Support modBUS-RTU protocol \ Free-Port communication protocol)</span>
   <div>
    &nbsp;
   </div>
   <div>
    &nbsp;
   </div><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Pt100, CU20, etc.</span>
   <div>
    &nbsp;
   </div><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Temperature range: -200 ~ +600℃,</span>
   <div>
    &nbsp;
   </div><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Accuracy: 0.5%,</span>
   <div>
    &nbsp;
   </div><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Measurement time: less than 1ms</span>
   <div>
    &nbsp;
   </div>
   <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Support four wire, three wire, two wire connection</span></p>
  </div>
  <p><img src="https://ae01.alicdn.com/kf/Hc73c37d7726a40198a06429f6ae39816J.jpg" style="margin:0.0px; padding:0.0px"></p>
  <p>&nbsp;</p>
  <p><img src="https://ae01.alicdn.com/kf/H784cd161f73b4f28941eecc81912f7bfu.jpg" style="margin:0.0px; padding:0.0px"></p>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Functional features</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">32-bit ARM processor</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Embedded real-time operating system</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Input channel: 8 channels</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Input type: Pt, Cu series thermal resistance</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Wiring mode: 2-wire system</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Sampling rate: 1 sampling point/second</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Resolution: 0.1℃</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Fine degrees: plus or minus 0.05%</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Support for remote firmware upgrade</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Supports periodic self-calibration</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Channel control (close/open, alarm setting)</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Operating temperature range: -25℃ ~ +85℃</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Measuring temperature range: -200 ~ +600℃,</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Plastic housing, standard DIN rail mounting</span></p>
  <p>&nbsp;</p>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Range of application</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Industrial field temperature control system</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Remote monitoring and data acquisition</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">Iron and steel, metallurgy, chemical industry</span></p>
  <div>
   &nbsp;
  </div>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">...</span></p>
  <p>&nbsp;</p>
  <p><span style="color:rgb(46, 48, 51); font-family:arial,microsoft yahei,,,malgun gothic,meiryo,sans-serif; font-size:14px">The accuracy of the negative temperature coefficient thermistor thermometer can reach 0.1℃, and the temperature induction time can be less than 1s. It is not only suitable for granary thermometer, but also can be used in food storage, medicine and health, scientific farming, ocean, deep well, high altitude, glacier and other aspects of temperature measurement.</span></p>
  <div>
   <p><img src="https://ae01.alicdn.com/kf/H4ea084a884bc4f9a99631b38a8bba235k.jpg" style="float:left; margin:0.0px; padding:0.0px; width:600.0px"></p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p>
   <p><img src="https://ae01.alicdn.com/kf/Ha40abf7e8b56498580aed8b7798b5200p.jpg" style="float:left; margin:0.0px; padding:0.0px; width:600.0px"></p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p> \
   <br>
    \
   <p>&nbsp;</p> \
   <p><strong><span style="font-size:15.0pt"><img src="https://ae01.alicdn.com/kf/H3a4d2182ed6047c3aa3a6b29a6e79f27F.jpg">&nbsp;</span></strong></p>
  </div>
 </div>
</div></div></div>
